C Series Module
Features: Brightness Switch or Fixed Output, DMF LightSpeed
Lumens: 1000 lm (13.6W), 1500 lm (17W), 2000 lm (24.5W)
Color Temperature: 3000K, 3500K, 4000K
Beam Spread: General Ambient (90°+)
Dimming: 0-10V (5%)
Ratings: Energy Star, Wet Location, Declare, RoHS Compliant, NSF/ANSI 2
Retrofit Kit
Features: Recessed, Wall Wash, Pinhole, Decorative, Warm Dim
Lumens: 750 lm (9.5W), 1000 lm (12.5W), 1250 lm (14.3W), 1500 (14.3W)
Color Temperature: 2700K, 3000K, 3500K, 4000K, Warm Dim (3000K – 1800K)
Trims: Round, Square, Wall Wash, Flangeless, Pinhole, Hyperbolic, Decorative
Rating: Energy Star, Title 24 JA8, Declare Listed, Wet Location, Dark Sky, NSF/ANSI 2
2” Downlight
Features: Recessed, Adjustable, Wall Wash, Decorative, Warm Dim, Tunable White
Lumens (Downlight): 500 lm (9.5W), 750 lm (9.5W), 1000 lm (12.5W), 1250 lm (14.3W), 1500 lm (14.3W)
Lumens (Adjustable): 500 lm (12.5W), 750 lm (12.5W), 1000 lm (14.3W)
Color Temperature: 2700K, 3000K, 3500K, 4000K, Warm Dim, Tunable White
Trims: Round, Square, Wall Wash, Flangeless, Pinhole, Hyperbolic, Decorative
Rating: Energy Star, Title 24 JA8, Declare Listed, Wet Location, Chicago Plenum, IC, Dark Sky, NSF/ANSI 2
X Series Module
Features: Adjustable, Field Changeable Optics, Integrated Driver, Warm Dim, Tunable White
Lumens: 500 lm (12.5W), 750 lm (12.5W), 1000 lm (14.3W)
Color Temperature: 2700K, 3000K, 3500K, 4000K, Warm Dim 3000-1800K, Tunable White 4000-1800K, Tunable White 6500-2700K
Beam Spread:10° Ultra Narrow Spot, 20° Narrow Spot, 30° Spot, 40° Flood, 50° Wide Flood, 50°x 30° Linear Spread
Dimming:0-10V 1%, TRIAC/ELV 1%, DALI 1%
Ratings: Energy Star, Title 24 JA8, Damp Location
4” Downlight
Features: Recessed, Adjustable, Wall Wash, Warm Dim, Multiple, Emergency, Decorative
Lumens: 750 lm (9.5W), 1000 lm (12.5W), 1250 lm (14.3W), 1500 lm (14.3W)
Color Temperature: 2700K, 3000K, 3500K, 4000K, Warm Dim, Tunable White
Trims: Round, Square, Hyperbolic, Pinhole, Wall Wash, Flangeless, Decorative, Emergency, Non-Conductive Dead Front
Ratings: Energy Star, Title 24 JA8, Declare Listed, Wet Location, Fire Rated, STC/IIC Sound Rated, Chicago Plenum, IC, NSF/ANSI 2 Splash Zone Safe
4” Downlight
Features: Recessed, Adjustable, Wall Wash, Decorative, Warm Dim, Tunable White, Emergency, Integrated Fixture Control
Lumens: 750 lm (9.5W), 1000 lm (12.5W), 1250 lm (14.3W), 1500 lm (14.3W), 2000 lm (24.5W), 2500 lm (27.5W), 3000 lm (34.0W), 3500 lm (40.5W)
Color Temperature: 2700K, 3000K, 3500K, 4000K, Warm Dim, Tunable White
Trims: Round, Square, Hyperbolic, Pinhole, Wall Wash, Flangeless, Decorative, Vandal, Emergency
Ratings: Energy Star, Declare Listed, RoHS Compliant, Wet Location, NSF/ASNI 2 Splash Zone Safe Listed, IP66, IK10, Anti-Microbial
4″ Cylinder (Formerly DCC)
Features: Surface Mount, Pendant, Wall Mount, Adjustable, Up/Down, Warm Dim, Emergency
Lumens: 750 lm (10W), 1000 lm (12W), 1250 lm (14W), 1500 lm (20W), 2000 lm (28W), 2500 lm (37W), 3000 lm (40W)
Color Temperature: 2700K, 3000K, 3500K, 4000K, Warm Dim, Tunable White
Trims: Round, Hyperbolic, Snoot, Decorative, Shade
Ratings: Energy Star, Title 24 JA8, Declare, IP65 Wet Location, NSF/ANSI 2 Splash Zone Safe, Dark Sky
3″ Cylinder
Features: Surface Mount, Pendant, Wall Mount, Up/Down, Wall Wash, Warm Dim, Tunable White
Lumens: 750 lm (9.5W), 1000 lm (12.5W), 1250 lm (14.3W)
Color Temperature: 2700K, 3000K, 3500K, 4000K, Warm Dim, Tunable White
Trims: Round, Snoot, Wall Wash (Coming Soon), Decorative (Coming Soon)
Ratings: Energy Star, Title 24 JA8, Wet Location
M Series Commercial Module
Features: Adjustable, Field Changeable Optics, Detachable Driver
Lumens: 750 lm (9.5W), 1000 lm (12.5W), 1250 lm (14.3W), 1500 lm (14.3W), 2000 lm (24.5W), 2500 lm (27.5W), 3000 lm (34.0W), 3500 lm (40.5W)
Color Temperature: 2700K, 3000K, 3500K, 4000K, Warm Dim, Tunable White
Beam Spread: 15° Narrow Spot, 25° Spot, 40° Flood
Dimming: 0-10V (1%), DALI-2 (0.1%)
Ratings: Damp Location, NSF/ANSI 2 Splash Zone Safe
M Series Commercial Module
Features: Field Changeable Optics, Integrated & Detachable Driver Options
Lumens: 750 lm (9.5W), 1000 lm (12.5W), 1250 lm (14.3W), 1500 lm (14.3W), 2000 lm (24.5W), 2500 lm (27.5W), 3000 lm (34.0W), 3500 lm (40.5W)
Color Temperature: 700K, 3000K, 3500K, 4000K, Warm Dim, Tunable White
Beam Spread: 15° Narrow Spot, 25° Spot, 40° Flood, 60° Wide Flood, 90° General Ambient
Dimming: 0-10V 1%, DALI-2 (0.1%)
Ratings: Wet Location, NSF/ANSI 2 Splash Zone Safe
M Series Residential Module
Features: Field Changeable Optics, Integrated Driver, Warm Dim, Tunable White
Lumens: 750 lm (9.5W), 1000 lm (12.5W), 1250 lm (14.3W), 1500 lm (14.3W)
Color Temperature: 2700K, 3000K, 3500K, 4000K, Warm Dim, Tunable White
Beam Spread: 15° Narrow Spot, 25° Spot, 40° Flood, 60° Wide Flood, 90°+ General Ambient, Linear, Soft Focus
Dimming: 0-10V 1%, TRIAC/ELV 1%, DALI 0.1%, Lutron EcoSystem 1%
Ratings: Energy Star, Title 24 JA8, Wet Location, NSF/ANSI 2 Splash Zone Safe
M Series Residential
Features : 360° directional aim, 45° tilt, Field Changeable Optics, Integrated Driver, Warm Dim
Lumens: 750 lm (9.7W), 1000 lm (12.0W)
Color Temperature: 2700K, 3000K, 3500K, 4000K, Warm Dim, Tunable White
Beam Spread: 15° Narrow Spot, 25° Spot, 40° Flood, Linear, Soft Focus
Dimming: 0-10V 1%, TRIAC/ELV 1%, DALI 0.1%, Lutron EcoSystem 1%
Ratings: Energy Star, Title 24 JA8, Damp Location, NSF/ANSI Splash Zone Safe
X Series Module
Features: Field Changeable Optics, Integrated Driver, Warm Dim, Tunable White
Lumens: 500 lm (9.5W), 750 lm (9.5W), 1000 lm (12.5W), 1250 lm (14.3W), 1500 lm (14.3W)
Color Temperature: 2700K, 3000K, 3500K, 4000K, Warm Dim 3000-1800K, Tunable White 4000-1800K, Tunable White 6500-2700K
Beam Spread: 25° Spot, 40° Flood, 60° Wide Flood, Linear Spread
Dimming: 0-10V (1%), TRIAC/ELV (1%), DALI (0.1%)
Ratings: Energy Star, Title 24 JA8, Wet Location
X Series Cylinder
Features: Surface Mount, Warm Dim, Tunable White
Lumens: 750 lm (9.5W), 1000 lm (12.5W), 1250 lm (14.3W), 1500 lm (14.3W)
Color Temperature: 2700K, 3000K, 3500K, 4000K, Warm Dim, Tunable White
Trims: Round, Snoot, Wall Wash (Coming soon), Decorative (Coming soon)
Ratings: Energy Star, Title 24 JA8, Wet Location
Most Versatile 4" Lighting Solutions
High Performance 2" Lighting Solutions
High Value 3" & 4" Lighting Solutions
Quick Shipping, Simple 4" & 6" Lighting Solutions
Slim Profile, Junction Box Solutions
